Super 5-Axis Gantry Machining Center KU- 2150/3150/4150/3220/4200/6300

Linear motion actuator

Mineral bed

Crown block structure

Linear motion actuator

Mineral bed

Crown block structure

Parameter/model	KU-2015	KU-3015	KU-4015	KU-3022	KU-4022	KU-6031
Table size	*20001500**	*30001500**	*40001500**	*30002200**	*40002200**	*60003100**
Travel x-axis mm	2000	3000	4000	3000	4000	6000
Travel y-axis mm	1500	1500	1500	2200	2200	3100
Travel z-axis mm	700	700	700	1000	1000	1000
Distance from spindle end face to table surface mm	200-900			200-1200		250-1250
Maximum load of workbench kg	3000	4000	5000	5000	5000	5000
Fast moving speed X/Y/Z axis m/min	60/60/60			48/48/36
Spindle type and speed rpm	HSK-A6320,000
Distance between two columns is mm.	2040			3000
Height from workbench to crossbeam mm	1187			1300
Rotation angle c	±105°+360°
Tool magazine form	Umbrella-type Arm-Type HSK-A63 30T
Transmission mode X/Y/Z axis	XY Li/Z screw of XY linear motor					X Linear motor Z screw Ball crew
Control system	Germany Rexroth MTX/XimingziSiemen
Positioning accuracy X/Y/Zmm	0.01/1000
Repetitive positioning accuracy X/Y/Zmm	0.008/1000
*Floor space (length width * height mm)**	*400039003650*	*500039003650*	*600039003650*	*600045005500*	*600045005500*	*1000065005000*
Total weight of machine tool kg	25000	30000	35000	35000	40000	65000
