Super machining center KS-500/600/800

Linear motion actuator

Mineral bed

Linear motion actuator

Mineral bed

Parameter/model	KS-500	KS-600	KS-800
Table size	*500400**	*650500**	*800650**
Travel x-axis mm	500	600	800
Travel y-axis mm	400	500	500
Travel z-axis mm	250	300	420
Distance from spindle end face to table surface mm	190-440	140-440	150-570
Maximum load of workbench kg	100	300	900
Fast moving speed X/Y/Z axis m/min	60/60/60	60/60/60	60/60/60
Acceleration X/Y/Z axis g	1	1	1
Spindle type and speed rpm	HSKE40-D120-30000	HSKE5O-D150-24000	HSKA63-D150-20000
Tool magazine form	Disc tool magazine 20T	Disc tool magazine 24T	Disc tool magazine 24T
Transmission mode X/Y/Z axis	Linear motion actuator	Linear motion actuator	Linear motion actuator
Control system	Rexroth Germany/Siemens/Heidenham
Positioning accuracy X/Y/Zmm	0.003	0.003	0.005
Repetitive positioning accuracy X/Y/Zmm	0.002	0.002	0.003
Floor space (length x width x height) mm	1800×2100×2400	2240×2000×2400	2700×2280×2470
Total weight of machine tool kg	5000	5500	8500
